Help for package HRTnomaly

Type:

Package

Classification/MSC-2010:

62G86

Title:

Historical, Relational, and Tail Anomaly-Detection Algorithms

Version:

25.2.25

Date:

2025-02-25

Maintainer:

Luca Sartore <drwolf85@gmail.com>

Description:

The presence of outliers in a dataset can substantially bias the results of statistical analyses. To correct for outliers, micro edits are manually performed on all records. A set of constraints and decision rules is typically used to aid the editing process. However, straightforward decision rules might overlook anomalies arising from disruption of linear relationships. Computationally efficient methods are provided to identify historical, tail, and relational anomalies at the data-entry level (Sartore et al., 2024; <doi:10.6339/24-JDS1136>). A score statistic is developed for each anomaly type, using a distribution-free approach motivated by the Bienaymé-Chebyshev's inequality, and fuzzy logic is used to detect cellwise outliers resulting from different types of anomalies. Each data entry is individually scored and individual scores are combined into a final score to determine anomalous entries. In contrast to fuzzy logic, Bayesian bootstrap and a Bayesian test based on empirical likelihoods are also provided as studied by Sartore et al. (2024; <doi:10.3390/stats7040073>). These algorithms allow for a more nuanced approach to outlier detection, as it can identify outliers at data-entry level which are not obviously distinct from the rest of the data. — This research was supported in part by the U.S. Department of Agriculture, National Agriculture Statistics Service. The findings and conclusions in this publication are those of the authors and should not be construed to represent any official USDA, or US Government determination or policy.

License:

AGPL-3

Depends:

R (≥ 4.0.0)

Imports:

dplyr, purrr, tidyr

Suggests:

knitr, rmarkdown, cellWise

Encoding:

UTF-8

LazyLoad:

yes

NeedsCompilation:

yes

ByteCompile:

TRUE

Packaged:

2025-02-25 23:46:06 UTC; sartore

Author:

Luca Sartore [aut] (ORCID = "0000-0002-0446-1328"), Luca Sartore [cre] (ORCID = "0000-0002-0446-1328"), Lu Chen [aut] (ORCID = "0000-0003-3387-3484"), Justin van Wart [aut], Andrew Dau [aut] (ORCID = "0009-0008-9482-5316"), Valbona Bejleri [aut] (ORCID = "0000-0001-9828-968X")

Repository:

CRAN

Date/Publication:

2025-02-26 12:40:16 UTC

HRTnomaly

Description

Enhanced Anomaly Detection for Historical, Relational, and Tail Cellwise Outlier

Details

Package:	HRTnomaly
Type:	Package
License:	AGPL-3

For a complete list of exported functions, use library(help = "HRTnomaly").

This research was supported by the U.S. Department of Agriculture, National Agriculture Statistics Service. The findings and conclusions in this publication are those of the authors and should not be construed to represent any official USDA or U.S. Government determination or policy.

Author(s)

Luca Sartore, Lu Chen, Justin van Wart, Andrew Dau, and Valbona Bejleri

Maintainer: Luca Sartore drwolf85@gmail.com

References

Agostinelli C, Leung A, Yohai VJ, Zamar RH (2015). Robust estimation of multivariate location and scatter in the presence of cellwise and casewise contamination. Test, 24(3): 441–461.

Alqallaf F, Van Aelst S, Yohai VJ, Zamar RH (2009). Propagation of outliers in multivariate data. The Annals of Statistics, 311–331.

Bienaymé IJ (1867). Considérations à l'appui de la découverte de Laplace sur la loi de probabilité dans la méthode des moindres carrés. Journal de Mathématiques Pures et Appliquées, 2(12): 158–176.

Chepulis MA, Shevlyakov G (2020). On outlier detection with the Chebyshev type inequalities. Journal of the Belarusian State University. Mathematics and Informatics, 3: 28–35.

Filzmoser P, Gregorich M (2020). Multivariate outlier detection in applied data analysis: Global, local, compositional and cellwise outliers. Mathematical Geosciences, 52(8): 1049–1066.

Gupta MM, Qi J (1991). Theory of t-norms and fuzzy inference methods. Fuzzy Sets and Systems, 40(3): 431–450.

Huber PJ, Ronchetti EM (1981). Robust statistics. John Wiley & Sons, New York.

O'Gorman TJ (1994). The effect of cosmic rays on the soft error rate of a DRAM at ground level. IEEE Transactions on Electron Devices, 41(4): 553–557.

Rousseeuw PJ, Van den Bossche W (2018). Detecting deviating data cells. Technometrics, 60(2): 135–145.

Sandqvist AP (2016). Identifizierung von Ausreissern in eindimensionalen gewichteten Umfragedaten. KOF Analysen, 2016(2): 45–56.

Sartore L, Chen L, Bejleri V (2024). Empirical Inferences Under Bayesian Framework to Identify Cellwise Outliers. Stats, 7: 1244–1258.

Sartore L, Chen L, van Wart J, Dau A, Bejleri V (2024). Identifying Anomalous Data Entries in Repeated Surveys. Journal of Data Science, 22(3): 436–455.

Tchebichef P (1867). Des valeurs moyennes. Journal de Mathématiques Pures et Appliquées, 2(12): 177–184.

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers using robust regression
res_c <- cellwise(toy[sample.int(33), ], epochs = 10L)
# Detect cellwise outliers using Bayesian testing
res_g <- bayesHRT(toy[sample.int(33), ], prior = 0.5)

# Detect record level outliers using Deep Isolation Forests
res_t <- dif(iris)

Calculate Cellwise Flags for Anomaly Detection Using Bayesian Testing

Description

The function uses the predictive posterior distribution based on emprical likelihoods to determine if a data entry is an outlier on not. The function takes a long-format data.frame object as input and returns it with two appended vectors. The first vector contains the posterior probabilities as numbers between zero and one, and the second vector provides a set of logical values indicating whether the data entry is an outlier (TRUE) or not (FALSE).

Usage

bayesHRT(a, prior = NULL)

Arguments

a

A long-format data.frame object with survey data. For details see information on the data format.

prior

A numerical value or vector of cell-level prior probabilites of observing an outlier. It is NULL by default. If false, the function searchers for a column named "prior" within the dataset. If such column is not provided in the dataset, a 0.5 non-informative value is used for all cells.

Details

The argument a is proivded as an object of class data.frame. This object is considered as a long-format data.frame, and it must have at least five columns with the following names:

"strata": a character or factor column containing the information on the stratification.
"unit_id": a character or factor column containing the ID of the statistical unit in the survey sample(x, size, replace = FALSE, prob = NULL).
"master_varname": a character column containing the name of the observed variable.
"current_value_num": a numeric the observed value, i.e., a data entrie
"pred_value": a numeric a value observed on a previous survey for the same variable if available. If not available, the value can be set to NA or NaN. When working with longitudinal data, the value can be set to a time-series forecast or a filtered value.
"prior": a numeric a value of prior probabilities of observign an outlier for the cell. If this column is omitted in the dataset provided, the function will use the values provided through the argument prior.

The data.frame object in input can have more columns, but the extra columns would be ignored in the analyses. However, these extra columns would be preserved in the system memory and returned along with the results from the cellwise outlier-detection analysis.

The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The long-format data.frame is provided as input data and contains extra columns i.e., anomaly flags and outlier posterior predictive distribution.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers
res <- bayesHRT(toy[sample.int(100), ], prior = 0.5)

Calculate Cellwise Flags for Anomaly Detection Using Robust Bayesian Methods

Description

The function uses a Bayesian approach to determine if a data entry is an outlier on not. The function takes a long-format data.frame object as input and returns it with two appended vectors. The first vector contains the posterior probabilities for a cell to be anomalous, and the second vector provides a set of logical values indicating whether the data entry is an outlier (TRUE) or not (FALSE).

Usage

bayeswise(a, prior = NULL, epochs = 1000L)

Arguments

a

A long-format data.frame object with survey data. For details see information on the data format.

prior

epochs

Number of epochs used to train a nontrivial robust linear model via the lion algorithm. By default, the algorithm will run 1000 iterations.

Details

The argument a is proivded as an object of class data.frame. This object is considered as a long-format data.frame, and it must have at least five columns with the following names:

"strata": a character or factor column containing the information on the stratification.
"unit_id": a character or factor column containing the ID of the statistical unit in the survey sample(x, size, replace = FALSE, prob = NULL).
"master_varname": a character column containing the name of the observed variable.
"current_value_num": a numeric the observed value, i.e., a data entrie
"pred_value": a numeric a value observed on a previous survey for the same variable if available. If not available, the value can be set to NA or NaN. When working with longitudinal data, the value can be set to a time-series forecast or a filtered value.
"prior": a numeric a value of prior probabilities of observign an outlier for the cell. If this column is omitted in the dataset provided, the function will use the values provided through the argument prior.

The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The long-format data.frame is provided as input data and contains extra columns i.e., anomaly flags and outlier indicators columns.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers using Bayesian Analysis
res <- bayeswise(toy[sample.int(100), ], 0.5, 10L)

Calculate Cellwise Flags for Anomaly Detection Using Bayesian Bootstrap

Description

The function uses Bayesian bootstrap to determine if a data entry is an outlier on not. The function takes a long-format data.frame object as input and returns it with two appended vectors. The first vector contains the anomaly scores as numbers between zero and one, and the second vector provides a set of logical values indicating whether the data entry is an outlier (TRUE) or not (FALSE).

Usage

bootHRT(a, contamination = 0.08, boot_max_it = 1000L)

Arguments

a

A long-format data.frame object with survey data. For details see information on the data format.

contamination

A number between zero and one used as a threshold when identifying outliers from the fuzzy scores. By default, the algorithm will identify approximately 8% of the data entries as anomalies.

boot_max_it

An integer number determining the iterations performed by Bayesian bootstrap algorithm. It is set to 1000 by default.

Details

The argument a is proivded as an object of class data.frame. This object is considered as a long-format data.frame, and it must have at least five columns with the following names:

"strata": a character or factor column containing the information on the stratification.
"unit_id": a character or factor column containing the ID of the statistical unit in the survey sample(x, size, replace = FALSE, prob = NULL).
"master_varname": a character column containing the name of the observed variable.
"current_value_num": a numeric the observed value, i.e., a data entrie
"pred_value": a numeric a value observed on a previous survey for the same variable if available. If not available, the value can be set to NA or NaN. When working with longitudinal data, the value can be set to a time-series forecast or a filtered value.

The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The long-format data.frame is provided as input data and contains extra columns i.e., anomaly flags and outlier indicators columns. The samples from the posterior distribution of the contamination threshold are attached as an attribute vector of length B named "thresholds".

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers
res <- bootHRT(toy, boot_max_it = 10)

Calculate Cellwise Flags for Anomaly Detection

Description

The function uses fuzzy logic to determine if a data entry is an outlier on not. The function takes a long-format data.frame object as input and returns it with two appended vectors. The first vector contains the anomaly scores as numbers between zero and one, and the second vector provides a set of logical values indicating whether the data entry is an outlier (TRUE) or not (FALSE).

Usage

cellwise(a, contamination = 0.08, epochs = 1000L)

Arguments

a

A long-format data.frame object with survey data. For details see information on the data format.

contamination

A number between zero and one used as a threshold when identifying outliers from the fuzzy scores. By default, the algorithm will identify 8% of the records as anomalies.

epochs

Number of epochs used to train a nontrivial robust linear model via the lion algorithm. By default, the algorithm will run 1000 iterations.

Details

The argument a is proivded as an object of class data.frame. This object is considered as a long-format data.frame, and it must have at least five columns with the following names:

"strata": a character or factor column containing the information on the stratification.
"unit_id": a character or factor column containing the ID of the statistical unit in the survey sample(x, size, replace = FALSE, prob = NULL).
"master_varname": a character column containing the name of the observed variable.
"current_value_num": a numeric the observed value, i.e., a data entrie
"pred_value": a numeric a value observed on a previous survey for the same variable if available. If not available, the value can be set to NA or NaN. When working with longitudinal data, the value can be set to a time-series forecast or a filtered value.

The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The long-format data.frame is provided as input data and contains extra columns i.e., anomaly flags and outlier indicators columns.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers
res <- cellwise(toy[sample.int(100), ], 0.05, 10L)

Evaluate the Accuracy of Outlier Classification Results

Description

The function computes the confusion matrix between the logical output of an outlier detection algorithm and a reference (ground-truth) logical vector. The function also calculates the overal accuracy of the results from the confusion matrix, including recall, precision, and F1-scores for the two classes (regular, versus outlier).

Usage

class_check(pred, truth)

Arguments

pred

A logical vector with the classification output from an anomaly detection algorithm.

truth

A logical vector with the observed classification as a reference (or ground truth).

Details

The function computes the confusion matrix using the function table. True positive and false negative are successively evaluated to compute overall accuracy, recall, precision, and F1-scores.

Value

An S3 class named checkwise with the confusion matrix, and other accuracy metrices appended as attribues.

attr(, "overall"): A numeric value between zero and one with the overall accuracy.
attr(, "recall"): A numeric vector of values between zero and one with the recall index for regular and outlier cells.
attr(, "precision"): A numeric vector of values between zero and one with the precision index for regular and outlier cells.
attr(, "f1-score"): A numeric vector of values between zero and one with the F1-scores for regular and outlier cells.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers using Bayesian Analysis
res <- cellwise(toy[sample.int(100), ], 0.5, 10L)
class_check(res$outlier, res$anomaly_flag != "")

Deep Isolation Forest

Description

The function builds a deep isolation forest that uses fuzzy logic to determine if a record is anomalous on not. The function takes a wide-format data.frame object as input and returns it with two appended vectors. The first vector contains the anomaly scores as numbers between zero and one, and the second vector provides a set of logical values indicating whether the records are outliers (TRUE) or not (FALSE).

Usage

dif(dta, nt = 100L, nss = NULL, threshold = 0.95)

Arguments

dta

A wide-format data.frame object with records (stored by row).

nt

Number of deep isolation trees to build to form the forest. By default, it is set to 100.

nss

Number of subsamples used to build a single deep isolation tree. If set (by default) to NULL, the program will randomly select 25% of the records provided to the dta argument.

threshold

A number between zero and one used as a threshold when identifying outliers from the anomaly scores. By default, this argument is set to 0.95, so that 5% of the records is going to be classified as anomalous.

Details

The argument dta is proivded as an object of class data.frame. This object is considered as a wide-format data.frame. The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The wide-format data.frame is provided as input data and contains extra columns, i.e., for both anomaly scores and the outlier flags.

Author(s)

Luca Scellwise artore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Detect outliers in the `iris` dataset
res <- dif(iris)

Calculate Cellwise Flags for Anomaly Detection

Description

Usage

fuzzyHRT(a, contamination = 0.08)

Arguments

a

A long-format data.frame object with survey data. For details see information on the data format.

contamination

A number between zero and one used as a threshold when identifying outliers from the fuzzy scores. By default, the algorithm will identify 8% of the records as anomalies.

Details

The argument a is proivded as an object of class data.frame. This object is considered as a long-format data.frame, and it must have at least five columns with the following names:

"strata": a character or factor column containing the information on the stratification.
"unit_id": a character or factor column containing the ID of the statistical unit in the survey sample(x, size, replace = FALSE, prob = NULL).
"master_varname": a character column containing the name of the observed variable.
"current_value_num": a numeric the observed value, i.e., a data entrie
"pred_value": a numeric a value observed on a previous survey for the same variable if available. If not available, the value can be set to NA or NaN. When working with longitudinal data, the value can be set to a time-series forecast or a filtered value.

The use of the R-packages dplyr, purrr, and tidyr is highly recommended to simplify the conversion of datasets between long and wide formats.

Value

The long-format data.frame is provided as input data and contains extra columns i.e., anomaly flags and outlier indicators columns.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers
res <- fuzzyHRT(toy[sample.int(100), ])

Generalized Isolation Forest

Description

The function builds a generalized isolation forest that uses fuzzy logic to determine if a record is anomalous on not. The function takes a wide-format data.frame object as input and returns it with two appended vectors. The first vector contains the anomaly scores as numbers between zero and one, and the second vector provides a set of logical values indicating whether the records are outliers (TRUE) or not (FALSE).

Usage

gif(dta, nt = 100L, nss = NULL, threshold = 0.95)

Arguments

dta

A wide-format data.frame object with records (stored by row).

nt

Number of generalized isolation trees to build to form the forest. By default, it is set to 100.

nss

Number of subsamples used to build a single generalized isolation tree. If set (by default) to NULL, the program will randomly select 25% of the records provided to the dta argument.

threshold

Details

Value

The wide-format data.frame is provided as input data and contains extra columns, i.e., for both anomaly scores and the outlier flags.

Author(s)

Luca Scellwise artore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Detect outliers in the `iris` dataset
res <- gif(iris)

A Method to Print the Accuracy of Outlier Classification Results

Description

The function print the confusion matrix and accuracy results previously computed with the function class_check.

Usage

  ## S3 method for class 'checkwise'
print(x, confusion = FALSE, ...)

Arguments

x

An S3 object of the class checkwise, typically computed with the function class_check.

confusion

A logical value, which is FALSE by default. If TRUE, the confusion matrix is printed after showing all accuracy metrics.

...

Additional arguments to pass to the function cat.

Details

The function computes the confusion matrix using the function table. True positive and false negative are successively evaluated to compute overall accuracy, recall, precision, and F1-scores.

Value

An S3 class named checkwise with the confusion matrix, and other accuracy metrics appended as attribues.

attr(, "overall"): A numeric value between zero and one with the overall accuracy.
attr(, "recall"): A numeric vector of values between zero and one with the recall index for regular and outlier cells.
attr(, "precision"): A numeric vector of values between zero and one with the precision index for regular and outlier cells.
attr(, "f1-score"): A numeric vector of values between zero and one with the F1-scores for regular and outlier cells.

Author(s)

Luca Sartore drwolf85@gmail.com

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the 'toy' data
data(toy)
# Detect cellwise outliers using Bayesian Analysis
res <- cellwise(toy[sample.int(100), ], 0.5, 10L)
class_check(res$outlier, res$anomaly_flag != "")

Set the number of CPU cores for HPC

Description

The function set the number of CPU cores for parallel computation by the use of OpenMP library (https://www.openmp.org/). If the package was not complied with the library OpenMP (>= 3.0), this function is disabled.

Usage

setCores(n)

Arguments

n

an integer value denoting the number of CPU cores to use; if it exceeds the total number of cores, all of them will be used. If missing, the number of CPU cores in use will be displayed.

Details

When the package is loaded, only one CPU core is used.

Value

The total number of CPU cores in use will be returned and a message will be displayed. If the package was not complied with the library OpenMP (>= 3.0), the value one will be returned.

Author(s)

Luca Sartore drwolf85@gmail.com

References

SunTM ONE Studio 8 (2003) OpenMP API User's Guide. Sun Microsystems Inc., Santa Clara, U.S.A.

Examples


#Display the number of CPU cores in use
setCores()

#Set 2 CPU cores for parallel computation
setCores(2)

#Set 1 CPU core for serial computation
setCores(1)

Toy dataset

Description

Synthetically produced data are provided to test the FuzzyHRT algorithm.

Usage

data(toy)

Format

The toy data is a data.frame object consisting of 9265 synthetic records and 5 variables:

strata: a numeric value of the strata
unit_id: a character string with the record ID
master_varname: a character string with the names of the variables
current_value_num: a numeric value with the current synthetic observation
pred_value: a numeric value with the previously synthetic observation

Examples

# Load the package
library(HRTnomaly)
set.seed(2025L)
# Load the toy dataset
data(toy)
# Detect cellwise outliers
res <- fuzzyHRT(toy)
